Features

• Improved efficiency
  The high performance cascade built in to the body boosts the applied voltage, which affects transfer efficiency, to -90kV.
  The wrap-around effect (the effect where charged paint wraps around the painted object, coating it right around to the reverse side) which is a feature of electrostatic coating, is maximized, resulting in superior paint transfer efficiency and contributing to less paint waste.
• Improved safety
  By combing the new spray gun with an HV Controller (RPI model) that is equipped with various safety detectors such as an Absolute sensitivity detection function (OL), a di/dt sensitivity detection function (SL), a constant voltage cable disconnection detection function (WT), and an HV transformer over-current detection function (OC), a more stabilized finishing quality is achieved and electrostatic coating safety is enhanced.
• Easier to maintain
  Because the unit is constucted so that the 3 way valve or trigger/dump valves are attached directly to the spray gun’s body, and because the high voltage generator (cascade) can be removed and replaced, maintenance has been made much easier.
• Various Nozzles
  Various nozzles are avaialble.
  You can select the fluid nozzle and air caps which meet your requirements.
• Independent control of Atomizing/Pattern Air
  Atomizing air and pattern air can be independently controlled.
  This enables high quality finishing which is best suited for the job at hand.
